MODEL : CADMX944CSpro

Product catalog PDF

  Introduction

This 4×4 4K HDMI Seamless Matrix Switcher & Video Wall Processor allows you to route any of the four HDMI inputs to any of the four HDMI outputs with smooth, zero‑delay switching. It also functions as a video wall processor, enabling 2‑, 3‑, or 4‑screen video wall layouts from a single source.

The device supports 4K30, is HDCP‑compliant, and offers flexible output scaling to 1080p, 720p, 1920×1200, and 4K30. Control options include front‑panel buttons, IR remote, and RS‑232, making it suitable for integration into professional AV setups.

Ideal for presentations, video conferencing, classrooms, retail displays, and multimedia demonstrations, this multifunctional switcher delivers reliable performance across a wide range of applications.

  Features

Video & Compliance

• HDCP 1.4 compliant

• Supports 10.2 Gbps HDMI bandwidth

• Input resolutions up to 4K @ 30Hz (HDMI 1.4b)

• Output resolutions scalable to:

  • 1080p

  • 720p

  • 1920×1200

  • 4K @ 30Hz

Operating Modes

• 4×4 Seamless Matrix Switching

• Video Wall Processor with layouts such as:

  • 2×2

  • 4×1

  • 1×4

  • Other custom configurations

Performance

• Seamless switching with zero delay and no picture loss

• Supports video wall mode with flexible splicing

• Output image mirror function

Audio Support

• Compatible with:

  • LPCM

  • Dolby Digital (DD)

  • Dolby Digital Plus (DD+)

  • DTS

Control Options

• Front panel buttons

• IR remote control

• RS‑232 command control

Design

• Compact, installer‑friendly design for flexible deployment

📦 Package Contents

1. 1× 4K 4×4 HDMI Seamless Matrix Switcher & Video Wall Processor

2. 1× Matrix IR Remote

3. 1× 3‑pin to 3.5mm Phoenix Connector (Male)

4. 2× Mounting Ears

5. 4× Machine Screws (KM3×4)

6. 1× 12V/1A Locking Power Adapter

7. 1× User Manual
