Medical Laproscopy Recorder With Universal Video Input, HDMI ,SDI ,VGA ,YPbPr , AV- Model CAD-RH60D || Medical Video Recorder- Multi-Input HD Surgical Recorder

Ideal For:

• Endoscopy recording

• Surgery video recording

• Hospital OT room documentation

• Medical training and research

• Multi-camera medical setups

✔This medical video recorder supports both digital and analog inputs, making it suitable for all types of hospital equipment.

✔It is widely used as a surgical video recorder in operation theatres for documenting critical procedures.

✔Hospitals can use it as an endoscopy video recorder to store, review, and share endoscopic footage safely.

✔The device functions as a hospital video recording system, ensuring accurate medical documentation and training support.

✔Its multi-input medical recorder design allows surgeons and technicians to connect HDMI, SDI, VGA, AV, and YPbPr sources seamlessly.

Specification：

Input Signal: HDMI/VGA/Component(YPbPr)/Composite(AV)/SDI

Output Signal: HDMI MAX bypass 1080P60FPS

SDI/HDMI/DVI/S-VIDEO/MMI Video input supports:

4K2K (3840x2160 30p),
1920x1080 (60p, 50p, 25p, 24p,30p, 60i, 50i)

1360x768 (60p), 1280x1024 (60p), 1280x720 (60p), 1280x768 (60P)

1280x800 (60p), 1024x768 (60p),720x480 (60p, 60i, 50i)

640x480(60p), 720x576 (50p),240p

Record Resolution:

1920x1080(60p),1280x720(60p),1024x768(60p),1280x800(60p)  H.264 MP4 Format

 Audio I/O Interface:

Line in/Line out/Mic(3.5mm Port)

Storage: 1T USB FLASH&1T SD CARD&HDD 8T

Support:OSD/Schedule/Playback/Snapshot/Remote Control

Support:FAT32/NTFS/exFAT/MBR/SSD/GPT etc.

Adapter Voltage:Input 100~240V 50/60Hz, Output 12V/1A/Less than 12W

Support:UVC OBS/VLC
